EDT315

Product Information

Specialized test bench for all brand of common rail & piezo injectors
Programme of automatic unitary operation tests

Common rail injectors
Common rail piezo injectors

The modern design of the test bench enables the diesel systems specialist to EDT 315 check any brand of Common Rail injector, including piezoelectric systems.

Thanks to the ongoing development of test records for all of the systems and the generation of new accessories, the EDT 315 is equipped to meet any market requirements.

EQUIPMENT COMPOSITION

EDT315 – LDFT 1118

EQUIPMENT

REF.
	CRI BOSCH CR INJECTORS KIT
	DELPHI CR INJECTORS KIT
	CRI DENSO CR INJECTORS KIT
	SIEMENS CR INJECTORS KIT
	BOSCH CR PIEZO INJECTORS KIT

ACCESORIES

REF.
LDFT1146	CABLE – 4 PIN DENSO INJECTORS TEST
LDFT1147	CABLE – DFI1.5 DELPHI INJECTORS TEST
LDFT0054	MACK RENAULT Ø 24 mm INJECTORS TEST KIT
LDFT0056	ACTROS Ø 26 mm INJECTORS TEST KIT
LDFT0057	MAN Ø 29 mm INJECTORS TEST KIT
LDFT0066	MAN Ø 29 mm H.53.50 INJECTORS TEST KIT
LDFT0058	MACK RENAULT Ø 27.5 mm INJECTORS TEST KIT
LDFT0059	RENAULT PREMIUM 420 CV Ø 32 mm INJECTORS TEST KIT
LDFT0055	CUMMINS Ø 26 mm INJECTORS TEST KIT
LDFT0061	DENSO Ø 27 mm INJECTORS TEST KIT
LDFT0062	DENSO Ø 23.5 mm INJECTORS TEST KIT
LDFT0063	MAN Ø 26 mm INJECTORS TEST KIT
LDFT0060	FIAT TECTOR Ø 26 mm INJECTORS TEST KIT
LDFT0064	VOLVO-DEUTZ Ø 24.5 mm INJECTORS TEST KIT
LDFT0065	DENSO Ø 32 mm INJECTORS TEST KIT
LDFT0067	DENSO Ø 27.0-28.5 mm INJECTORS TEST KIT
LDFT0068	PERKINS Ø 19.5 mm INJECTORS TEST KIT
LDFT0069	SIEMENS FORD PIEZO Ø 27 mm INJECTORS TEST KIT
LDFT0070	CR DEUTZ Ø 21 mm INJECTORS TEST KIT
LDFT0071	SCANIA/CUMMINS XPI-ISX INJECTORS TEST KIT
LDFT0072	MAN-DAEWOO INJECTORS TEST KIT
LDFT0073	BOSCH 4 PIN MERCEDES Ø 35 mm INJECTORS TEST KIT
LDFT1149	MERCEDES-MITSUBISHI FUSO INJECTORS TEST KIT
LDFT1150	RAPID NOZZLE CONNECTOR D.9 mm

TECHNICAL SPECIFICATIONS

EDT315 – LDFT 1118

DRIVE SYSTEM

MOTOR	3 PHASE 400 VAC or 220 VAC 50/60 HZ
POWER	5 kW

MEASURE SYSTEM

MEASUREMENT SYSTEM	Tolerance repeatability 1%l
INJECTION TIME MEASUREMENT	Nozzle response time sensors (Optional)

FEED SYSTEM

OIL TANK	10 l
REFRIGERATION	Integrated refrigeration system: without water – without air
MAXIMUM PRESSURE	2,000 Bar
FILTRATION	Capacity up to 3μ

COMPUTING SYSTEM

OPERATING SYSTEM	Microsoft Windows 10
SOFTWARE	HAWK
SCREEN	10.1″ touchscreen
CONNECTIONS	Wi-Fi, bluetooth, microSD and HDMI

OPERATION SYSTEM

Nozzle and return leak tests
Measurement of injection quantity at:
- Pre-injection (VE)
- Idle speed (LL)
- Emissions (EM)
- Full load (VL)
Diagnosis of electrical coil and its condition (graph on monitor)
Minimum opening pressure detection (Optional)
Minimum opening time detection (Optional)
Detection of response time (Optional)
Detection of lack of spray (Optional)

DIMENSIONS

HEIGHT	870 mm
WIDTH	1,010 mm
DEPTH	770 mm
VOLUME	0.7 m³
WEIGHT	170 kg
BODY CONSTRUCTION	Nickel-plated iron
SAFETY DOOR	Transparent plexiglas protector Immediate stoppage of the motor if opened

INFORMATION SYSTEM

MULTIBRAND	All brands
TEST RECORDS	Generation and storage of test records Printing of reports with achievable reference values
SETTINGS	Personalised data tables
UPDATING	Via the internet
SOURCES	Original specifications from the manufacturers
